Getting Started with Reference Sourcing Conditions
How-to GuideStep-by-step guides to achieve a specific scenario or setup.
Author:
Kirill Gaiduk
Changed on:
3 Sept 2026
Key Points
Master the Core Mechanism: Path Conditions extract values from the Sourcing Context, apply an operator, and evaluate them against configured value. Readers will understand how these checks return true/false outcomes that drive sourcing decisions
Handle Arrays with Care: Always define a `conditionScope` (ALL, ANY, NONE) when targeting collections. This ensures predictable results and prevents evaluation errors
Validate Parameters Rigorously: Use correct paths, operators, and value types. Misconfigured operators, unresolved paths, or type mismatches are the most common causes of Condition failures
Know When to Customize: Path Conditions cover most scenarios, but complex multi-field or non-standard requirements may call for registering a custom Condition type
The Path Condition is a configurable function that evaluates data in the Sourcing Context and produces a true or false outcome. It extracts a value(s) from a specified path, applies an operator, compares it with a configured value, and, when necessary, aggregates results across arrays using a `conditionScope`.During Strategy evaluation, the framework instantiates the reference implementation `DefaultSourcingCondition` for conditions of type `fc.sourcing.condition.path` and evaluates it through `evaluateWithResult`, which returns the pass or fail outcome together with the actual value for auditing. Its `evaluateWithContext` method delegates to the same `evaluateWithResult`, so custom Conditions that implement only the boolean method behave consistently.
Internal Mechanics
The reference implementation processes Conditions through the following sequence:
Resolves the JSON path with `JsonUtils.getPath(sourcingContext, path)` to locate the node
Flattens arrays when multiple values exist, ensuring that nested arrays are evaluated consistently
Applies the configured `conditionScope`:
ALL: every element must satisfy the operator
ANY: at least one element must satisfy the operator
NONE: no element may satisfy the operator
Compares the resolved values against the configured value using the operator retrieved from `SourcingConditionOperatorRegistry`
Captures the resolved value(s) it evaluated as the Condition's actual value alongside the pass or fail outcome, which the framework records per Condition for the Sourcing Audit through `evaluateWithResult`
Applying Path Conditions to Real Scenarios
Path Conditions are best suited for logic that depend on a single field or a collection within the Sourcing Context. Practical scenarios include:
Checking Order timestamps (`createdOn`) with `greater_than`, `less_than`, or `between`
Validating Customer attributes such as `customer.attributes.byName.tier` with `in`
Filtering by delivery information, for example `fulfilmentChoice.address.country` with `in`.
Evaluating Product or Item properties over arrays, such as `unfulfilledItems.product.ref` combined with `ALL` or `ANY`.
Parameter Definitions
Each Path Condition instance relies on the following parameters:
`path`(`String`): The JSON path in the Sourcing Context. Examples:
`createdOn`
`fulfilmentChoice.address.country`
`unfulfilledItems.product.ref`
`operator` (`String`): The comparison method. Supported operators:
`value` (UI component enforces correct input type): The target value(s)
(optional) `conditionScope` (`String`): Determines how array results are aggregated. Options (`SourcingConditionConstants`):
`ALL`
`ANY`
`NONE`
Configuration in the UI
The reference schema in `fc.rubix.order.sourcing.conditions` Setting defines templates for Path Conditions. Each template specifies the operator, UI component, and validation logic, ensuring accurate input during configuration.For account/retailer-specific adjustments, override Conditions in `fc.rubix.order.sourcing.conditions.custom`. When a Condition with the same `name` exists in both schemas, the custom schema takes precedence, allowing organizations to adapt global definitions to local business needs without breaking the baseline.
Non-value nodes: Adjust the path so it resolves to a scalar rather than an object
Array mismatches: Add a `conditionScope` when targeting collections such as Items or Categories
Operator errors: Ensure the operator string matches a registered operator in `SourcingConditionOperatorRegistry`
Type mismatches: Provide values in the expected format (ISO dates, numbers, or exact strings)
Range confusion: Confirm inclusivity rules when using between or comparison operators
Best Practices
Use descriptive names that reflect business intent
Start with reference templates before creating custom overrides
Always define `conditionScope` explicitly for array paths
Provide exact values and enforce strict types through schema-driven components
Test boundary and edge cases thoroughly
Apply overrides in `fc.rubix.order.sourcing.conditions.custom` when tailoring conditions for specific Accounts / Retailers
Key constraints to keep in mind
The `path` must resolve to a scalar value node (string, number, boolean, or datetime)
When targeting arrays, always set `conditionScope` explicitly
Invalid or missing operator and scope definitions result in evaluation errors
Tip
When business requirements involve complex multi-field checks or unconventional data sources, consider registering a custom Condition type. For most use cases, the Path Condition is sufficient.
1mutation createSourcingProfile($input: CreateSourcingProfileInput) {
2 createSourcingProfile (input: $input) {
3 id
4 ref
5 version
6 versionComment
7 name
8 description
9 status
10 user {
11 id
12 }
13 createdOn
14 updatedOn
15 retailer {
16 id
17 }
18 defaultVirtualCatalogue {
19 ref
20 }
21 defaultNetwork {
22 ref
23 }
24 defaultMaxSplit
25 sourcingStrategies {
26 id
27 ref
28 sourcingProfile {
29 id
30 }
31 name
32 description
33 status
34 priority
35 createdOn
36 updatedOn
37 virtualCatalogue {
38 ref
39 }
40 network {
41 ref
42 }
43 maxSplit
44 sourcingConditions {
45 name
46 type
47 params
48 }
49 sourcingCriteria {
50 name
51 type
52 params
53 }
54 }
55 sourcingFallbackStrategies {
56 id
57 ref
58 sourcingProfile {
59 id
60 }
61 name
62 description
63 status
64 priority
65 createdOn
66 updatedOn
67 virtualCatalogue {
68 ref
69 }
70 network {
71 ref
72 }
73 maxSplit
74 sourcingConditions {
75 name
76 type
77 params
78 }
79 sourcingCriteria {
80 name
81 type
82 params
83 }
84 }
85 }
86}
1{2"input":{3"ref":"Puget_Sound",4"versionComment":"First version of Puget_Sound",5"name":"Puget_Sound",6"description":"Profile Description",7"retailer":{8"id":19},10"defaultVirtualCatalogue":{11"ref":"BASE:PS"12},13"defaultNetwork":{14"ref":"PS"15},16"defaultMaxSplit":5,17"sourcingStrategies":[18{19"ref":"Seattle_Metro",20"name":"Seattle_Metro",21"description":"Seattle_Metro Sourcing Strategy",22"status":"ACTIVE",23"network":{24"ref":"SM"25},26"sourcingConditions":[27{28"name":"deliveryRegionIn",29"type":"fc.sourcing.condition.path",30"params":{31"path":"fulfilmentChoice.address.region",32"operator":"in",33"value":"Seattle Metro"34}35}36],37"sourcingCriteria":[38{39"name":"networkPriority",40"type":"fc.sourcing.criterion.networkPriority",41"params":{42"value":[43"SM_LS",44"SM_WH"45]46}47},48{49"name":"locationDistance",50"type":"fc.sourcing.criterion.locationDistance"51}52]53},54{55"ref":"San_Juan_Islands",56"name":"San_Juan_Islands",57"description":"San_Juan_Islands Sourcing Strategy",58"status":"ACTIVE",59"network":{60"ref":"SJI"61},62"sourcingConditions":[63{64"name":"deliveryRegionIn",65"type":"fc.sourcing.condition.path",66"params":{67"path":"fulfilmentChoice.address.region",68"operator":"in",69"value":"San Juan Islands"70}71}72],73"sourcingCriteria":[74{75"name":"networkPriority",76"type":"fc.sourcing.criterion.networkPriority",77"params":{78"value":[79"SJI_LS",80"SM_WH"81]82}83},84{85"name":"locationDistance",86"type":"fc.sourcing.criterion.locationDistance"87}88]89}90],91"sourcingFallbackStrategies":[92{93"ref":"Coastal",94"name":"Coastal",95"description":"Coastal Strategy Description",96"status":"ACTIVE",97"sourcingConditions":[98{99"name":"allProductSizeIn",100"type":"fc.sourcing.condition.path",101"params":{102"path":"unfulfilledItems.product.attributes.byName.size",103"operator":"in",104"value":[105"Extra-Small",106"Small"107],108"conditionScope":"ALL"109}110}111],112"sourcingCriteria":[113{114"name":"locationDistanceExclusion",115"type":"fc.sourcing.criterion.locationDistanceExсlusion",116"params":{117"value":50,118"valueUnit":"miles"119}120},121{122"name":"orderValue",123"type":"fc.sourcing.criterion.orderValue"124}125]126}127]128}129}
1{2"data":{3"createSourcingProfile":{4"id":"333",5"ref":"Puget_Sound",6"version":1,7"versionComment":"First version of Puget_Sound",8"name":"Puget_Sound",9"description":"Profile Description",10"status":"ACTIVE",11"user":{12"id":"1302"13},14"createdOn":"2025-08-18T13:41:40.774Z",15"updatedOn":"2025-08-18T13:41:40.774Z",16"retailer":{17"id":"1"18},19"defaultVirtualCatalogue":{20"ref":"BASE:PS"21},22"defaultNetwork":{23"ref":"PS"24},25"defaultMaxSplit":5,26"sourcingStrategies":[27{28"id":"516",29"ref":"Seattle_Metro",30"sourcingProfile":{31"id":"333"32},33"name":"Seattle_Metro",34"description":"Seattle_Metro Sourcing Strategy",35"status":"ACTIVE",36"priority":1,37"createdOn":"2025-08-18T13:41:40.787Z",38"updatedOn":"2025-08-18T13:41:40.787Z",39"virtualCatalogue":null,40"network":{41"ref":"SM"42},43"maxSplit":null,44"sourcingConditions":[45{46"name":"deliveryRegionIn",47"type":"fc.sourcing.condition.path",48"params":{49"path":"fulfilmentChoice.address.region",50"value":"Seattle Metro",51"operator":"in"52}53}54],55"sourcingCriteria":[56{57"name":"networkPriority",58"type":"fc.sourcing.criterion.networkPriority",59"params":{60"value":[61"SM_LS",62"SM_WH"63]64}65},66{67"name":"locationDistance",68"type":"fc.sourcing.criterion.locationDistance",69"params":null70}71]72},73{74"id":"517",75"ref":"San_Juan_Islands",76"sourcingProfile":{77"id":"333"78},79"name":"San_Juan_Islands",80"description":"San_Juan_Islands Sourcing Strategy",81"status":"ACTIVE",82"priority":2,83"createdOn":"2025-08-18T13:41:40.782Z",84"updatedOn":"2025-08-18T13:41:40.782Z",85"virtualCatalogue":null,86"network":{87"ref":"SJI"88},89"maxSplit":null,90"sourcingConditions":[91{92"name":"deliveryRegionIn",93"type":"fc.sourcing.condition.path",94"params":{95"path":"fulfilmentChoice.address.region",96"value":"San Juan Islands",97"operator":"in"98}99}100],101"sourcingCriteria":[102{103"name":"networkPriority",104"type":"fc.sourcing.criterion.networkPriority",105"params":{106"value":[107"SJI_LS",108"SM_WH"109]110}111},112{113"name":"locationDistance",114"type":"fc.sourcing.criterion.locationDistance",115"params":null116}117]118}119],120"sourcingFallbackStrategies":[121{122"id":"315",123"ref":"Coastal",124"sourcingProfile":{125"id":"333"126},127"name":"Coastal",128"description":"Coastal Strategy Description",129"status":"ACTIVE",130"priority":1,131"createdOn":"2025-08-18T13:41:40.781Z",132"updatedOn":"2025-08-18T13:41:40.781Z",133"virtualCatalogue":null,134"network":null,135"maxSplit":null,136"sourcingConditions":[137{138"name":"allProductSizeIn",139"type":"fc.sourcing.condition.path",140"params":{141"path":"unfulfilledItems.product.attributes.byName.size",142"value":[143"Extra-Small",144"Small"145],146"operator":"in",147"conditionScope":"ALL"148}149}150],151"sourcingCriteria":[152{153"name":"locationDistanceExclusion",154"type":"fc.sourcing.criterion.locationDistanceExсlusion",155"params":{156"value":50,157"valueUnit":"miles"158}159},160{161"name":"orderValue",162"type":"fc.sourcing.criterion.orderValue",163"params":null164}165]166}167]168}169}170}
