Changed on:

1 Nov 2024

Overview

This course introduces the Fluent OMX UX Framework, and aims to enable business and functional consultants to configure custom Web Apps on the Fluent OMX Platform

Understand what the UX Framework is
Understand how a Fluent Web App is constructed
Understand what the Component Library is
Be able to Configure the Manifest document

Summary

Why did we build it?

Author:

Fluent Commerce

Changed on:

18 Oct 2024

Overview

[Warning: empty required content area]

Key points

[Warning: empty required content area]

Changed on:

23 Sept 2024

Overview

[Warning: empty required content area]

Key points

[Warning: empty required content area]

Changed on:

23 Sept 2024

Overview

The OMX Component Library is a suite of UI Components, ready to be configured and used in Fluent Web Apps.Unlike a standard UI Component, Fluent Components are built to natively interact with the Fluent Platform.The Library contains a number of different types of Components, including:

Foundation Components, such as Page Components which form the base of a screen
Content Components for displaying data and media
Layout Components for structuring pages
Interaction Components for capturing user input

Key points

Foundation Components, such as Page Components which form the base of a screen
Content Components for displaying data and media
Layout Components for structuring pages
Interaction Components for capturing user input

Learn more about the Foundation, Content, Layout and Interaction Components:Foundation Components

Content Components

Layout Components

Interaction Components

User Action Inline Component

Additionally, there is a Library of Field Components which are automatically rendered in User Action forms:

Changed on:

23 Sept 2024

Overview

Foundation Components are a category of components within the OMX Component Library.Foundation Components are top level components that map to a specific URL path within the Web App.Page Components are the primary foundation component, as they layout the page area, and provide a content area for child components to be displayed.

Key points

[Warning: empty required content area]

FoundaPage components are mobile responsive, so the screens render perfectly for any device.Different Page Components are available within the Library, and you can create your own too. For example, you may wish to use a simple, clean page component with minimal header information or a more advanced wizard-style page to help users through a step-by-step process.Learn more about the Foundation Components

Changed on:

23 Sept 2024

Overview

Content Components are components that display information, including data or media.
They can range from simple card components to advanced multimedia or graphical components.

Key points

[Warning: empty required content area]

Content Components typically display data from the configured Page query, but some may display information retrieved via a component specific API call.Content Components are typically added as descendants to Page components to form screens.Learn more about the Content Components

Changed on:

23 Sept 2024

Overview

[Warning: empty required content area]

Key points

[Warning: empty required content area]

Layout Components provide additional structural elements to the screen.For example, you may wish to layout your page into multiple sections, each with a header and actions. No alt provided

Or, you may want to display tabs which show different components or data based on which is active. No alt provided

Another example is to conditionally display components, based on an entity type for example.Like Foundation Components, Layout Components have descendants, which identify what should be displayed for that layout.Learn more about the Layout Components

Changed on:

23 Sept 2024

Overview

[Warning: empty required content area]

Key points

[Warning: empty required content area]

Interaction Components allow users to interact with the OMS.Interaction Components could be a form to capture information, or a button to execute an action. No alt provided

These are not to be confused with the standard user actions, which display buttons in the page header, and slide out a right hand drawer for form display.Rather, these components can be added directly to a screen just like any other component.Learn more about the Interaction Components

User Action Inline Component

Changed on:

23 Sept 2024

Overview

[Warning: empty required content area]

Key points

[Warning: empty required content area]

Field Components are a different kind of component all together.They cannot be configured via the manifest. Rather, they are automatically rendered based on the data type to be captured.Field Components are essentially form based elements. They could be as simple as a text box, or more advanced with multiple input fields and types.Field Components are key in delivering flexibility and enhanced user experience to complex user actions driven by the workflow. Workflows can require complex data input for the expected trigger event, and Field components enable full control over the user experience provided for those cases. No alt provided

Example:

In the screenshot above, the Requested Quantity and the Location selection are 2 parts to a single field, which map to an Event Attribute structured as follows:

1{
2
3    "name": "StockReserveDetails",
4    "value": {
5        "locationRef": "F_NSYD",
6        "requestedQuantity": 2
7    },
8    "type": "STOCK_RESERVE_DETAILS"
9}

Since Field Components are rendered automatically based on the User Action definition, there is no configuration reference required.Learn more about the Field Components

Changed on:

23 Sept 2024

Overview

We've provided a VS Code Workspace project, which comes preconfigured with the Manifest Schemas to enable Auto-Complete in VS Code.Simply download the attached Zip file, extract it on your computer, and open the workspace file in VS Code.Once complete, type "Done" into the "Your Response/Notes" form, select "Movyn John OR Randy Chan" as your instructor, and then click "Submit Assignment".
Please Note:Before you can start following the online course practically, you will need your Fluent Account credentials.If you have not yet received your credentials, please type "Waiting for Credentials" into the response form, or email learning@fluentcommerce.com to request them.
Please allow up to 48 hours to receive the email with details.

Key points

[Warning: empty required content area]

Changed on:

23 Sept 2024

Overview

[Warning: empty required content area]

Key points

[Warning: empty required content area]

The Manifest document describes the structure and layout of a Fluent Web App, including the navigation, and all pages within the application.

The manifest document is added as an ACCOUNT level setting.

The name defined in the manifest determines the URL path required to access the Fluent Web App.

For example, a manifest declaring a name or "mywebapp" would be accessible via the following URL:

https://[ACCOUNTID].sandbox.apps.fluentcommerce.com/mywebapp/

The manifest also determines the context of the Web App, either "retailer" or "location", and delivers Role based visibility management, so that each Web App and screen can be configured based on each client's unique organisational structure.

The manifest also defines the data to be provided to the page via GraphQL queries.

Watch the video below to see a simple new manifest document structure...

Note: This video does not have audio.

Account level setting

Creating a Web App is as simple as creating an Account level setting with the following naming convention:`fc.mystique.manifest.[appName]`...where [appName] is the name of the web app. The Setting should be a JSON type, and store the manifest document in the JSON value. To access the web app, you would use the following URL:`https://[ACCOUNTID].sandbox.apps.fluentcommerce.com/[appName]/`Each Fluent Web App should a define Name, a Title, a Context, and a set of Routes.The Context is the scope of interaction with the Fluent Order Management system.For example, the Fluent Store Web App is set to a Location Context, since all the actions and data present within the Web App are specific to an individual Store.A Retailer Context Web App would provide Retailer scoped actions and data management.Routes are the URL paths that point to Pages or screens.There are 3 types of Routes that can be configured in a Manifest:

A Page Route - which is a direct link to a page
A Section Route - which is a navigation grouping header
A Reference Route - which is a reference to another manifest document called a fragment, which allows you to split and manage large manifests in separate documents

Watch the video below to see how to create a new app...To follow along on your own training account, log in to Fluent Admin Console using the FC_FASHION retailer user: `fc_fashion_admin`Note: This video does not have audio.

Since this web app was configured to a `location` context in the manifest, use a Location user login, such as F_syd@fcfashion.com.au, to log in and view the empty app.

Since this web app was configured to a ``location`` context in the manifest, use a Location user login, such as `F_syd@fcfashion.com.au`, to log in and view the empty app.Note: Don't worry about the "error" text displayed - we'll fix this next!Let's add a simple Page route to the Manifest:A Page Route should be set to type "page", declare a relative URL path, use a foundation or page based component, and optionally a nav configuration for the main menu.Once you have your first page, you can now set your web app's home path.Let's see it in action...Note: This video does not have audio.Learn more about configuring the manifest document.

Changed on:

23 Sept 2024

Overview

Key points

[Warning: empty required content area]

There are 2 types of manifest document format. The primary type is the main web application manifest, and the second type is a fragment which can be referenced from the main Manifest document.The main manifest document structure is as follows:`{`
` "manifestVersion": "2.0",`
` "name": "store",`
` "title": "Fluent Store",`
` "context": {`
` "level": "location"`
` },`
` "routes": MystiqueRoute[]`
`}`The required fields include:

manifestVersion
name
title
context
routes

Additionally, a main manifest can also set the homePath, which is the default path to load on login.The Context configuration defines that the App either operates at a LOCATION level or at a RETAILER level. You can also declare that a user should have a specific role assigned in that context in order to be allowed access to the App.Routes are what drive the Navigation menu drawer. The simplest type of Route is a Section route, which simply defines navigation group header. For example, you may want to group a number of top level menu items under a section called "Admin", or "Customer Service", or "Inventory Management" for example. No alt provided

The primary Route type is a page route. This defines a specific page to display when the user clicks on the navigation item. No alt provided

Finally, there are Reference routes, which provide manifest fragmentation capability, so that you do not need to manage the whole UI configuration in a single (and very large) JSON document.`{`
` "type": "reference",`
` "settingName": "fc.mystique.manifest.servicepoint.fragment.pickandpack"`
`}`The structure of a fragment Manifest is as follows:`{`
` "manifestVersion": "2.0",`
` "routes": MystiqueRoutes[]`
`}`Finally, the Manifest document can also be configured to read custom plugins containing custom components referenced within the Manifest.`"plugins": [{`
` "name": "Example",`
` "src": "https://example.com/bundle.js"`
`}]`
For more information, and to learn how to configure each part of the Manifest document, see the Configuration Guide.

Changed on:

23 Sept 2024

Overview

[Warning: empty required content area]

Key points

[Warning: empty required content area]

Let's imagine our client would like to see all the Storage Areas available within a Store. We can easily add this capability to the Fluent Store Web App code free! First, watch the video below to see how to create a new Manifest Fragment document... Note: This video does have audio.

[Warning: empty required content area]

Next we need to add this fragment to the Account Settings, and then reference it in the Fluent Store Manifest document.

Next we need to add this fragment to the Account Settings, and then reference it in the Fluent Store Manifest document.The main Fluent Store Manifest Document is already added to your Training Account. See the following Account Setting: `fc.mystique.manifest.store`If you do not have this setting, or you would like to update it, download the main store manifest.The Fluent Store URL: `https://[ACCOUNTID].sandbox.apps.fluentcommerce.com/store/`Note: Replace "`[ACCOUNTID]`" with your assigned Training Account, e.g.: `FCTRAINAU001`Log in to the Store app using the F_SYD Location User:
Username: `F_syd@fcfashion.com.au`
Password: `1234`Watch the video below to see how it's done...Note: This video does have audio.

Changed on:

23 Sept 2024

Overview

We now need to display all the Storage Areas associated to this Store.To do this, we'll use the standard List Component provided by the Component Library.First, let's add the component to our page...Note: This video does not have audio

Key points

[Warning: empty required content area]

In the next lesson, we'll provide some real data from the API to the list.For more information and configuration options, see the List Component documentation.

Changed on:

23 Sept 2024

Overview

In order to show data in the Storage Areas List, we need to configure a data source.Components on a page can reference a data source from a query defined on the Page Component.First, we'll configure a page query, to retrieve the currently active Location's associated Storage Areas.The `data` object on the Page Route takes a `query` and a `variables` object for defining a GraphQL Query.`"data": {`

`"query": "query locationStorageAreas ($locationRef: String!) { location (ref: $locationRef) { id ref storageAreas { edges { node { id name status type } } } } }",`

`"variables": {``"locationRef": "{{activeLocation.ref}}"``}``}`You'll notice the use of a special variable called `{{activeLocation.ref}}` above. Since this Web App Context is "location", you can access the currently active context using the `activeLocation` object. This provides access to the Location Id, Ref, and Primary Address.Once the Page query is defined, go to the Component configuration, and add a `dataSource` field. The `dataSource` for the list should be set to the `storageAreas` connection on the `location` query path: `location.storageAreas` `"dataSource": "location.storageAreas"`With the data source configured, all that's left is to update the fields to be displayed in the list with dynamic values. We'll display the Name, Type, and Status from the Storage Area.This is done by specifying the field of each node in the Storage Areas connection: `{{node.name}}` `"attributes": [``{``"label": "Name",`
`"value": "{{node.name}}"``},``{``"label": "Type",`
`"value": "{{node.type}}"``},``{``"label": "Status",`
`"value": "{{node.status}}"``}``]`See this in action in the video below...Note: This video does not have audio.

Key points

[Warning: empty required content area]

Configure a data source

Learn more about configuring the Page query in the Page Routes section on this page.Learn more about Dynamic Attributes on this page.

Changed on:

23 Sept 2024

Overview

In this lesson, we'll show you how to create a details page for a specific item in a list, and hyperlink the list to the detail page.Note: This video does have audio.

Key points

[Warning: empty required content area]

Add a detail page

Changed on:

23 Sept 2024

Overview

Next we'll configure our Details page with a page query, similarly to the listing page.For the details page, we'll query the storageAreaById query, and retrieve the associated articles connection.Watch below to see this in action...Note: This video does not have audio

Key points

[Warning: empty required content area]

Next we'll configure our Details page with a page query, similarly to the listing page. For the details page, we'll query the storageAreaById query, and retrieve the associated articles connection. Watch below to see this in action... Note: This video does not have audio

Now that we have our Storage Area Summary information, and have set it to half screen width, let's add a list to display the associated Articles.Note: This video does not have audio

Configure components

Changed on:

30 Apr 2025

Overview

The Framework provides some useful features for working with dynamic data.First, let's consider the Date and Time based data. The Framework provides a useful dateStringFormatter to help format the raw date values in more readable forms.Take a look at the follow video to see this in action.Note: Currently the ability to associate an Article with a Storage Area is not supported in the Training Accounts. This will be resolved in future.Note: This video does not have audio.

Key points

[Warning: empty required content area]

Working with variables date formatting

For more information on helper functions available to the dynamic values, read about Template Strings on this page.

Changed on:

23 Sept 2024

Overview

There are also some useful features for working with arrays. Typically you can access an array item by its index as follows: `node.attributes.0.value`This works on edges too: `node.aticles.edges.0.node.ref`Now, you can retrieve Attributes by Name: `node.attributes.byName.Size`In our example, the Article associated to the Storage Area contains an attribute named "FulfilmentType". See how we can show this in the Articles list below.Note: This video does not have audio.

Key points

[Warning: empty required content area]

Working with variables attributes by name

You can render images in lists and cards by specifying the component attribute type as "image". This also allows additional options to be provided to the image html that is generated.`{`
`   "type" : "image",`
`   "value" : "{{attributes.byName.imageUrl}}",`
`   "options" : {`
` "width" : 220`
`   }`
`} `Read more about configuring Dynamic Attributes on this page.

Changed on:

23 Sept 2024

Overview

In this lesson we show you how to configure the i18n Language translation keys for your Fluent Web App.Note: This video does have audio.

Key points

[Warning: empty required content area]
