| Azure AD | SCIM User Resource | ←Mapping & Transformation→ | Fluent Commerce User | Required | Notes |
| userPrincipalName | userName |
| ref, username | yes | Unique User Identifier, Login name |
| N/A | password | Not used - Defaulted to random uuid string | password | yes | mandatory for fluent |
| givenName | name.givenName |
| firstName |
|
|
| surname | name.familyName |
| lastName |
|
|
| mail | emails[type eq "work"].value | Filter by primary = true | primaryEmail | yes | User Primary Email |
| telephoneNumber | phoneNumbers[type eq "work"].value | Filter by primary = true | primaryPhone |
| User Primary Phone |
| Switch([IsSoftDeleted], , "False", "True", "True", "False") | active | For active=true set status=ACTIVE For active=false set status=INACTIVE | status |
| Indicates if User is active or not. |
| AppRoleAssignmentsComplex([appRoleAssignments]) | roles |
| roles |
| The list of user assigned roles. Please note that roles could be mapped directly or via a dynamic mapping pipeline based on configuration. |
| userType | Not used - Defaulted to RETAILER | type | yes | Defaulted to RETAILER. The type of the user can have the following values [ACCOUNT, ADMIN, AGENT, API, DEBUG, GLOBAL, RETAILER, SUPPORT]. Scim protocol definition: Used to identify the organization to user relationship. Typical values used might be 'Contractor', 'Employee', 'Intern', 'Temp', 'External', and 'Unknown' but any value may be used. |
| timezone | Not used - Defaulted to AU-Sydney | timezone | yes | The User's time zone in the 'Olson' timezone database format; e.g.,'America/Los_Angeles' |
